The 1060 aluminum sheet is the definition of industrial pure aluminum, boasting a minimum 99.6% aluminum content.
The 1060 aluminum sheet is the definition of industrial pure aluminum, boasting a minimum 99.6% aluminum content. This high purity level makes it one of the most versatile and cost-effective materials for applications where excellent electrical conductivity, corrosion resistance, and easy workability are paramount. While its strength is lower than alloyed grades, its unmatched combination of key properties makes it an indispensable material across countless industries.
1. Electrical Industry: The primary material for busbars, electrical connectors, and capacitor shells due to its superior conductivity
2. Construction & Architecture: Used in wall cladding, decorative panels, signage, and nameplates thanks to its aesthetic appeal and weather resistance.
3. Consumer Goods: Found in kitchen utensils, lampshades, fan blades, and decorative items.
4. Chemical Industry: Suitable for chemical storage tanks and lining that handle certain chemicals, leveraging its corrosion resistance.
5. General Manufacturing: Ideal for spun hollowware, stamping parts, and heat sinks where complex forming is required.
|
Alloy |
1060 |
|
Temper |
F,O,H12,H14,H16,H18,H19,H22,H24,H26,H28,H111,H112,H114 |
|
Thickness（mm） |
0.1-600 |
|
Width（mm） |
100-2600 |
|
Length（mm） |
500-15000 |
|
Key Feature |
Best corrosion resistance and electrical/thermal conductivity in the aluminum family. |
|
Alloy |
Si |
Fe |
Cu |
Mn |
Mg |
Cr |
Ni |
Zn |
V |
Ti |
Zr |
Others |
Al |
|
1060 |
0.25 |
0.35 |
0.06 |
0.03 |
0.03 |
|
|
0.05 |
0.05 |
0.03 |
|
0.03 |
99.6 |
The high purity creates a tenacious oxide layer, providing outstanding resistance to atmospheric corrosion, making it ideal for both indoor and outdoor applications without the need for costly coatings.
Its conductivity is second only to copper among common metals, but at a fraction of the weight and cost, making it the premier choice for electrical busbars, conductors, and heat exchangers.
With high ductility and elongation, the 1060 sheet can be easily stamped, deeply drawn, bent, and spun into complex shapes without cracking, simplifying your fabrication process.
The bright, clean surface offers high reflectivity for both light and heat, perfect for light fixtures, reflectors, and decorative trim.
As a non-heat-treatable alloy with a simple production process, it delivers reliable performance at a highly competitive price point.
"We rely on 1060 aluminum sheet for all our electrical busbar projects. Its perfect balance of high conductivity, ease of fabrication, and cost allows us to deliver reliable performance to our clients without exceeding budget."
— Project Engineer, Electrical Systems Integrator
