3105 Aluminum sheet belongs to the Al-Mn series of rust-proof aluminum alloys and is a core representative of the 3000 series aluminum sheets.
3105 Aluminum sheet belongs to the Al-Mn series of rust-proof aluminum alloys and is a core representative of the 3000 series aluminum sheets. Its tensile strength ranges from 120 to 160 MPa, with a yield strength of ≥85 MPa, combining excellent ductility and corrosion resistance. This material cannot be strengthened through heat treatment but can enhance mechanical properties through cold working. It is widely used in deep drawing and decorative applications. Key features include:
|
Alloy |
3105 |
|
Temper |
O,H12,H14,H16,H18,H19,H22,H24,H26,H28,H112,etc. |
|
Thickness (mm) |
1.0-500 |
|
Width (mm) |
100-2650 |
|
Length (mm) |
500-16000 |
|
Package |
Export packaging (protective film, interleaved paper) |
|
Application |
Wine bottle caps, beverage bottle caps, cosmetic caps, coated rolls, etc. |
|
Alloy |
Si |
Fe |
Cu |
Mn |
Mg |
Zn |
Ti |
Others |
Al |
|
3105 |
≤0.6 |
≤0.7 |
≤0.3 |
0.3-0.8 |
0.2-0.8 |
≤0.40 |
≤0.10 |
≤0.15 |
Remainer |
|
Alloy |
Temper |
Thickness(mm) |
Tensile strength(Rm/Mpa) |
Elongation(%) |
Earing ratio (%) |
|
3105 |
H14,H24 |
0.2-0.5 |
150-200 |
2 |
4 |
|
3105 |
H16,H26 |
0.2-0.5 |
175-225 |
1 |
4 |
|
3105 |
H18 |
0.2-0.5 |
≥195 |
1 |
4 |
Manganese forms a dense oxide layer, resisting salt, alkali, and acid rain corrosion—ideal for humid environments.
Contains 0.3% copper, achieving 41% conductivity, making it suitable for electronic component housings.
It features excellent deep-drawing, forming, and welding capabilities, facilitating the production of complex-shaped parts and improving manufacturing efficiency.
Low density (2.73 g/cm³) reduces transportation and installation costs while improving structural efficiency.
Recyclable, complies with green building standards, and reduces carbon emissions.
More affordable than 5000-series aluminum alloys, widely used in the market, lowering overall costs.
