5182 Aluminum sheet is a typical high-corrosion-resistant alloy sheet from the Al-Mg series, with core components including 4.0%-5.0% magnesium and trace amounts of manganese and chromium. Through optimized composition, it achieves a balance between strength and plasticity.
5182 Aluminum sheet is a typical high-corrosion-resistant alloy sheet from the Al-Mg series, with core components including 4.0%-5.0% magnesium and trace amounts of manganese and chromium. Through optimized composition, it achieves a balance between strength and plasticity. Its tensile strength reaches 240-300 MPa (depending on heat treatment state), with a yield strength ≥110 MPa and elongation ≥18%, offering excellent fatigue resistance and stress corrosion cracking resistance. Available in thicknesses ranging from 0.2 to 500 mm and supporting custom cutting, it is widely used in automotive safety structural components, marine engineering, and tank manufacturing, complying with international standards such as EN 485 and ASTM B209.
|
Alloy |
5182 aluminum sheet sheet |
|
Temper |
O,H12,H14,H16,H18,H19,H22,H24,H26,H28,H32,H34,H36,H38,H111,H112,H114,H116,H321,etc. |
|
Thickness(mm) |
0.15-600 |
|
Width(mm) |
100-2650 |
|
Length(mm) |
500-16000 |
|
Surface treatment |
Rolled, patterned aluminum sheet |
|
Package |
Export packaging (protective film, interleaved paper) |
|
Certificate |
CCS, ABS, BV，LR, ISO |
|
Application |
The outboard of a ship’s side bottom, deck, refrigeration equipment, tank car, auto parts, etc. |
Low density with strong energy absorption per unit mass, effectively reducing structural weight.
Excellent performance in marine and chemical environments, extending service life.
Performs well in gas welding and TIG welding with low crack susceptibility.
Easy to stamp and stretch-form without cracking.
High recyclability reduces operational and maintenance costs, aligning with green development needs.
