Aluminium alloy composite plate for brazing, also known as brazing sheet, is a specialized multi-layer material engineered for high-strength, leak-proof joining in heat exchanger manufacturing. It typically consists of a core alloy (like 3003) clad on one or both sides with a lower-melting-point aluminium-silicon alloy (like 4045 or 4343).
Aluminium alloy composite plate for brazing, also known as brazing sheet, is a specialized multi-layer material engineered for high-strength, leak-proof joining in heat exchanger manufacturing. It typically consists of a core alloy (like 3003) clad on one or both sides with a lower-melting-point aluminium-silicon alloy (like 4045 or 4343). During the controlled atmosphere brazing (CAB) or vacuum brazing process, the clad layer melts and flows to form seamless joints without melting the core, creating strong, durable, and corrosion-resistant heat exchange components.
New Energy Vehicle (NEV) Heat Exchangers: For cooling electric motors, power electronics, and onboard chargers.
Automobile Radiators & Condensers: As the core material in engine cooling systems for both traditional and hybrid vehicles.
EV Battery Cooling Plates: Essential for maintaining optimal temperature in battery packs, ensuring safety, performance, and longevity.
HVAC & Air Conditioning Systems: Used in evaporators and condensers for automotive and building climate control.
Industrial Heat Exchangers: Applicable in various machinery and energy systems for cooling and heating processes.
|
Alloy (Core/Clad) |
3003/4343, 3003/4045, 6061/4045 |
|
Temper |
O, H14, H24 |
|
Thickness (mm) |
0.3 – 3.0 mm |
|
Width (mm) |
500 – 1500 mm |
|
Standard Coil Weight |
1,000 – 5,000 kg |
The integrated brazing clad layer eliminates separate filler metal application, simplifying assembly and reducing process steps.
Ensures strong, uniform, and leak-proof seams thanks to the controlled flow of the clad material during brazing.
Aluminum’s low density helps reduce the overall weight of thermal systems, contributing directly to improved energy efficiency.
Lowers material and labor costs by minimizing filler usage and enabling high-volume, automated brazing processes.
Aluminum alloys offer inherent oxidation resistance, often enhanced with treatments, ensuring long service life in demanding environments.
